What it does

This tool renders the Mandelbrot set in real time with WebGL and keeps the navigation fluid even as you zoom well past the range where ordinary single precision shaders start to fall apart.

The renderer uses double-float emulation in the fragment shader, splitting each coordinate into high and low float parts to preserve more useful precision.

How to use it

• Open: https://tedt.org/tools/fractal.html
• Scroll to zoom toward or away from the cursor.
• Drag with the left mouse button to pan.
• Double-click to zoom in faster.
• Double-right-click to zoom out.
• Single-click to recenter on a point.

Notes

• This tool requires WebGL.
• The HUD shows the current center coordinates, scale, depth, and iteration cap.
• Interior points render black; escaping points use a smooth cyclic palette.

Precision model

Typical WebGL Mandelbrot demos rely on single-precision floats, which limits how far you can zoom before coordinates smear or collapse. This version uploads the center position as float32 high and low parts and reconstructs arithmetic in the shader, pushing usable exploration deeper while remaining fully client-side.
